Moon by Simaudio Two Channel Integrated Amplifier - 700iv2 (2-Tone)

Moon by Simaudio Two Channel Integrated Amplifier - 700iv2 (2-Tone)

Moon by Simaudio Two Channel Integrated Amplifier - 700iv2 (2-Tone)
Moon by Simaudio Two Channel Integrated Amplifier - 700iv2 (2-Tone)
Moon by Simaudio Two Channel Integrated Amplifier - 700iv2 (2-Tone)
FAST DELIVERY
FAST DELIVERY
Authorized Dealer
Free Shipping
$19800 CAD / Each
Call Now For Best Price (705) 445-1118

Or as low as $550.00/month. Apply Now

Authorized Dealer
Free Shipping
$19800 CAD / Each
Call Now For Best Price (705) 445-1118

Or as low as $550.00/month. Apply Now



Friendly, Personal, Professional Attention.
Expert, Sales, Service, Custom In-Home Installation, with On-Going Support at Guaranteed Low Prices! ….Since 1989!


Friendly, Personal, Professional Attention.
Expert, Sales, Service, Custom In-Home Installation, with On-Going Support at Guaranteed Low Prices! ….Since 1989!
Literature

Feature rich: input labelling, gain offset

Design features

  • Our “Lynx” Technology eliminates the global feedback loop and results in the following: more accurate musical reproduction with respect to tonality; the elimination of common phase errors resulting from feedback.
  • An oversized dual-mono power supply.
  • “Class A” power output to 5 watts for greater efficiency.
  • Gain offset adjustment of ±10dB for each input.
  • Any input is configurable to become a “bypass input”, whereby the 700i v2’s volume control is bypassed, permitting a plethora of applications including usage in a home-theater environment.
Specifications
Output Power at 8Ω175 W per channel
Output Power at 4Ω350 W per channel
Input Impedance23 700 Ω
Inputs (RCA / XLR)4 pairs / 1 pair
Monitor Loop (RCA)1 pair
Gain37 dB
Frequency response (full range)10Hz - 100kHz +0/-0.1dB
Crosstalk @ 1kHz-100 dB
THD (20Hz - 20kHz @ 1 W)0.015 %
THD (20Hz - 20kHz @ 175 W)0.04 %
Intermodulation distortion0.02 %
Shipping weight62 lb / 28 kg
Dimensions (width x height x depth)18.75 x 5.5 x 18.1 in 47.6 x 14.0 x 46.0 cm
