Invisible Series
Specifications | |
---|---|
Tweeter | 4 sq. in (27 sq. cm) planar diaphragm, driven by a 1" (25mm) voice coil |
Midrange | 17 sq. in (110 sq. cm) planar diaphragm, driven by a 1" (25mm) voice coil |
Woofer | 113 sq. in (732 sq. cm) planar diaphragm, driven by a 2" (50mm) voice coil |
Frequency Response | 40Hz - 20kHz ±3dB |
Impedance | 8 ohms nominal; 6 ohms minimum |
Power Handling | 100 watts RMS |
Sensitivity | 90dB SPL (1 watt/1 meter) |
Dispersion | 170º hemispherical up to 10kHz |
Finish | Paper surface ready for up to 1/8" (3mm) flexible material* and paint *Pliable, elastic material such as joint compound, plaster or wallpaper. |
Overload Protection | Three independent self-resetting gel switches (low, mid and high) |
Environment Temperature | 0º - 125º F (-17.7º - 51.7º C) |
Speaker Depth | 2" (51mm) 3 11/16in (94mm) with optional Enclosure |
Shipping Weight | 25 lbs (11.25kg) pair |
UL Rating | — |
Cut-Out Dimensions (W x H) | 16 1/8" x 24 5/32" (409.5mm x 613.5mm) |
Transformer | — |
